MPC-6000 / MPC-7000 / RND-2 PROGRAMMING MANUAL
28
Below are the different parameters that may be set for each of the different devices:
Loop Devices
FireSmart
Smoke
Detector
Thermal
Detector
Smoke
Detector
Pull
station
Single
input
monitor
module
Dual
input
monitor
module
Single
input
monitor
module
with relay
Conven-
tional
Zone
module
LED
output
Intelligent
Point
Control
(See note 4)
Parameter
8713 8712 8710 8700-Single
8700-Dual
8700-Metal
8701
8702
8703 8704 8705 8726 8706
Label X X X X X X X X X X
Application X - - - - - - - - -
Sensitivity
When app
off
- X - - - - - - -
ROR
-
X - - - - - - - -
Led off X X X - X X X X - X
Pre-alarm
When app
off
- X - - - - - - -
Verification
When app
off *
- X - - - - X** - -
Alarm X X X X X X X X - -
Waterflow - - - - X X X X - -
Sil. Waterflow - - - - X X X X - -
Trouble - - - - X X X - - X****
Supervisory X - X - X X X X - -
Panel reset - - - - X X X - - -
Alarm silence - - - - X X X - - -
Acknowledge - - - - X X X - - -
Test - - - - X X*** X - - -
Manual Pull - - - - - - X - -
Abort
2, 3
- - - - X X X - - -
Man. Release
1, 3
- - - X X X X - - -
Thermal
1
- X - - X X X - - -
* Except when used in DUCT application. *** Available only for first input usage.
** Except when used for manual pull station. **** Input usage inherently set to trouble.
1
Thermal and manual release usage devices generate an alarm condition.
2
Abort usage devices will only generate an abort condition when initiated during a Pre-discharge
condition.
3
These features are only available with releasing operations.
4
8706 modules can only be assigned to addresses 1-60.
NOTE: When programming requires yes or no, press 1 for YES and 0 for NO.
The following table provides a description of the parameters that may be set for each device.
Parameter Description
Label Each device may have a forty character label assigned to it to describe the input. This label
will be displayed when the input becomes active.
Application The FireSmart detectors have internal algorithms that may be set for different environments.
A setting of “none” turns off the algorithms and allows the detector sensitivity to be set
manually and verification to be selected.
Sensitivity This sets the level of smoke that will cause the device to generate an alarm. This is only
appropriate for smoke detectors.
Norm Open Relay contact are normally open. EOL is required. This applies to 8702, 8703 and 8704.
Norm Clos
Relay contacts are normally closed. No EOL is required. This applies to 8702, 8703 and 8704.
