MPC-6000 / MPC-7000 / RND-2 PROGRAMMING MANUAL
3
The Operator Interface
Interface for User and Maintenance Levels
The operator interface for configuring and programming the MPC-6000/7000 uses the 4
line by 20 character LCD display, the M1 through M4 buttons on the left and right of the
display and sixteen push buttons at the bottom of the interface. User Level and
Maintenance Level utilize the LCD display and the four buttons (two on each side of the
display) to navigate and alter the basic operation of the panel. The display will show
messages in the four corners of the display that will be adjacent to the four buttons M1
through M4. The message on the display adjacent to the button indicates the action that
will occur when the button is pressed. Therefore pressing M1 will cause the function
labeled as “Menu 1” to be pressed.
M1 or 1 M3 or A
M2 or * M4 or D
Note: When programming in Technician Level, M1=1 on the keypad, M2=* on the
keypad, M3=A on the keypad and M4=D on the keypad.
For example, in the following figure, menu item 1 (Lamp Test) is described as having an
Action of ‘Run Lamp Test’. If the button next to Lamp Test is depressed, Lamp Test will
be performed. Menu item 2 (View History) will cause the first event in the event history
to be displayed on the screen.
Action: Run Lamp Test Returns to the top of the
list or to the level up
Will display panel go to the next screen
History
Lamp Test Esc
View
History More
Menu 1 Menu 3
Menu 2 Menu 4
