TROUBLESHOOTING ST100 Series Flow Meter
46 Fluid Components International LLC
DISCONNECT SENSOR
WIRES AND PLUG
IN FES-200 CABLE
REMOTE ELECTRONICS
FES-200 CABLE
TP1 HEATER
CURRENT
THUMBWHEEL
SWITCHES
C01254-1-1
Reference Sensor
H
L
G
Active Sensor
H
L
G
1 HTR EXC #1
3 HTR RTN
4 ACT EXC
5 ACT SEN
6 GND SEN
7 GND
8 REF EXC
9 REF SEN
TB1
110 Ω
10 W
Figure 25 - ST100 Decade Box Wiring
C01255-1-1
Figure 24 - Remote Configuration
FES-200 Connected at Electronics
