PLEASE NOTE:
- The number of inputs and/or outputs must
be rounded up to the next word limit.
- If the number of input bits differs from the
number of output bits, the larger number is
decisive for entering the process data
channel bits.
- The status bits of a valve terminal with
inputs occupy an additional four inputs.
The table belows summarizes the possible
number of bits for the process data channel.
Equipment on valve
terminal
Process data channel bits
Up to 12 + 4 inputs 16
Up to 28 + 4 inputs 32
Up to 44 + 4 inputs 48
Up to 60 + 4 inputs 64
Up to 16 outputs
1
16
Up to 32 outputs
1
32
Up to 48 outputs
1
48
Up to 64 outputs
1
64
1
Valve coils and/or electrical outputs
• Device Type
The default entry "Remote bus device" can
be transferred.
• Save these entries with "OK. "
VIFB6 - 03/05 4. Commissioning
9809c 4-19
