Festo 03 - 2.3 TYPE 05: FITTING THE VALVE TERMINAL

2.3 TYPE 05: FITTING THE VALVE TERMINAL
Wall fitting (type 05)
WARNING
With long terminals use additional support
brackets approximately every 200 mm.
You thereby avoid:
• overloading the fastening eyes
on the end plates
• the terminal sagging (I/O side)
• natural resonances
Proceed as follows:
• Calculate the weight of your terminal (weigh
or estimate). General rule:
• Make sure that the fastening surface can
carry this weight.
ISO size 1 ISO size 2
Sub-base
*)
- 4 valve locations
incl. valves
- 8 valve locations
incl. valves
- 12 valve locations
incl. valves
8 kg
14 kg
20 kg
12 kg
20 kg
28 kg
per node 1 kg
per electronic module 0.4 kg
*)
Components for vertical stacking:
Please see pneumatics manual P.BE-ISO-GB
for weights.
VIFB6 - 03/05 2. Fitting
2-12
