PLEASE NOTE
Maximum 64 outputs per valve terminal can
be addressed on INTERBUS.
2. Inputs
The address assignment of the inputs does
not depend on the outputs.
2.1 Addressing the input modules
•
Addresses should be assigned in
ascending order without gaps.
•
Counting on the node is
from right to left.
•
Counting on the individual modules must
be from top to bottom.
•
4-input modules occupy 4 addresses.
•
8-input modules occupy 8 addresses.
2.2 Status bits
The address assignment of the status bits
depends on the fitting variants of the
inputs and the configuration.
The following always applies:
• The status bits are only available when input
modules are connected to the terminal and
when at least eight inputs are configured.
• Addressing:
The status bits are transferred to the four hig-
hest-value positions of the configured address
area.
PLEASE NOTE
Maximum 64 inputs per valve terminal (60
digital inputs and 4 status bits) can be ad-
dressed on INTERBUS
.
VIFB6 - 03/05 4. Commissioning
