A. Technical appendix
A-6
Festo P.BE-CB-COMP-EN en 1102d
Code ActionCause
F05 Material jam (warning)
Signal on plug PLC O/23 = HIGH
The Checkbox has not received
any conveyed par ts for at least
30 seconds
1)
.
1) Duration variable, can be set with
CheckKo n
– With manual feed: Acknowledge faults, supply further
inspection par ts or stop the Checkbox.
– With a utomatic supply: Fill up small parts conveyor,
check feed path for material jam,
acknowledge warning.
E06 Maximum permitted par ts
length exceeded
Fault E 06 is shown only if the
CheckKon function “Forced
abort of analysis” is switched
on.
– With CheckKon: Set the parameter “Max. parts length”
correctly
– Set the conveyor device so that the par t s
follow each other at a recognizable distance.
E07 Visual fault:
Reduced brightness
Clean the glass surfaces on the prism.
E08 Only for operation with
encoder:
Conveyor device blocked or
encoder does not turn.
Checkbox has no control over the conveyor device.
– Check the fitting and installation of the encoder.
E09
E10
Overload of internal
I/O module
1. Stop the Checkbox
2. Check whether external outputs are loaded with an
excessive current
3. Star t the Checkbox
or contact t he Festo after-sales servic e.
E12 Overtemperature – Check ambient temperature
– Prevent warmth from outside e.g. by sun shine.
E14 Only for operation with
encoder:
Conveyor speed for the set
ratio encoder frequency/
line frequency of the camera
(F
EZ
v alue) too high.
– Reduce conveyo r speed
–WithCheckKon:AdaptF
EZ
value.
E19 Incorrect operating system The o perating system must be appropriate f or the
CHB-C-X.
– Install correct operating system variant.
