Festo CPX-CMAX - Permitted CPX Bus Nodes and Control Blocks

1 Safety and requirements for product use
Festo – P.BE-CPX-CMAX-SYS-EN – en 2017-09b – English 13
Specified standards
Version status
EN 60204-1:2006-06/A1:2009-02 ISO 8573-1:2010
Tab. 1.1 Standards specified in the document
1.2.5 Permitted CPX bus nodes and control blocks
The following CPX bus nodes and control blocks are approved for operation with the CMAX axis control
ler starting with the revisions named here (at the time this description was printed). Older revisions are
not supported and can lead to unpredictable behaviour.
Current information on this è catalogue from Festo (è www.festo.com/catalogue).
Observe the notes on the software status in the documentation for the bus node or con
trol block.
Bus node/
control block
Protocol Approved revision
1)
Max. number
2)
CMAX
CPX-CEC (Control block) Revision 5 and above 8
CPX-FEC Revision 19 (R19) and above 8
CPX-CEC-C1 Revision 7 (R7) and above 8
CPX-CEC-M1 Revision 3 (R3) and above 8
CPX-FB6 Interbus Revision 22 (R22) and above 1
CPX-FB11 DeviceNet Revision 20 (R20) and above 8
CPX-FB13 PROFIBUS-DP Revision 23 (R23) and above 8, 7
3)
CPX-FB14 CANopen Revision 20 (R20) and above 4
CPX-M-FB20 Interbus Revision 2 (R2) and above 1
CPX-M-FB21 Interbus Revision 2 (R2) and above 1
CPX-FB23-24 CC-Link (function module F23) Revision 19 (R19) and above 4
CC-Link (function module F24) 8
CPX-FB32 EtherNet/IP Revision 14 (R14) and above 8
CPX-FB33 PROFINET Revision 7 (R7) and above 8
CPX-M-FB34 Revision 7 (R7) and above 8
CPX-M-FB35 Revision (R20) and above 8
CPX-FB36 EtherNet/IP Revision 5 (R5) and above 8
CPX-FB38 EtherCAT All 8
1) Revision status (Rev...) è Product label.
2) The maximum number within a CPX terminal can be further restricted through the available address range.
3) If acyclic services (DPV1) are used, a maximum of 7 CMAX modules are permitted.
Tab. 1.2 Required revisions
