3 Mounting and pneumatic installation
28 Festo – P.BE-CPX-CMAX-SYS-EN – en 2017-09b – English
3.4 Proportional directional control valve VPWP
3.4.1 Approved drive/valve combinations
Tab. 3.6 contains the approved drive-valve combination at the time this description was printed.
 Use the specified fittings and compressed air tubing or appropriate hoses with corresponding flow
rates.
Current information è www.festo.com/catalogue.
Drive Valve Fitting Compressed
air tubing
Type Size Length [mm] Valve Drive
DDLI 25 100 … 160 VPWP-4-... QS-G1/8-6 QS-G1/8-6 PUN-6x1
225 … 600 QS-G1/8-8 QS-G1/8-8 PUN-8x1,25
750 … 2000 VPWP-6-...
32 100 VPWP-4-... QS-G1/8-6 QS-G1/8-6 PUN-6x1
160 … 360 QS-G1/8-8 QS-G1/8-8 PUN-8x1,25
450 … 2000 VPWP-6-...
40 100 … 300 VPWP-4-... QS-G1/8-8 QS-G1/4-8 PUN-8x1,25
360 … 750 VPWP-6-...
850 … 2000 VPWP-8-... QS-G1/4-10 QS-G1/4-10 PUN-10x1,5
63 100 … 300 VPWP-6-... QS-G1/8-8 QS-G3/8-8 PUN-8x1,25
360 … 450 VPWP-8-... QS-G1/4-10 QS-G3/8-10 PUN-10x1,5
500 … 750
Q/
QS-G3/8-12
2)
,5
850 … 2000 VPWP-10-... QS-G3/8-12 QS-G3/8-12 PUN-12x2
DDPC 80 100 … 200 VPWP-6-... QS-G1/8-8 QS-G3/8-8 PUN-8x1,25
201 … 450 VPWP-8-... QS-G1/4-10 QS-G3/8-10 PUN-10x1,5
451 … 750 VPWP-10-... QS-G3/8-12 QS-G3/8-12 PUN-12x2
100 100 … 120 VPWP-6-... QS-G1/8-8 QS-G1/2-12
1)
PUN-8x1,25
121 … 330 VPWP-8-... QS-G1/4-10 QS-G1/2-12
2)
PUN-10x1,5
331 … 750 VPWP-10-... QS-G3/8-12 QS-G1/2-12 PUN-12x2
DGCI 18 100 … 2000 VPWP-4-... QS-G1/8-6 QSM-M5-6 PUN-6x1
25 100 … 160 VPWP-4-... QS-G1/8-6 QS-G1/8-6
225 … 600 QS-G1/8-8 QS-G1/8-8 PUN-8x1,25
750 … 2000 VPWP-6-...
32 100 … 400 VPWP-4-... QS-G1/8-8 QS-G1/8-8 PUN-8x1,25
450 … 2000 VPWP-6-...
1) With additional reduction from @ 12 to @ 8, with push-in connector QS-12H-8
2) With additional reduction from @ 12 to @ 10, with push-in connector QS-12H-10
