3 Mounting and pneumatic installation
Festo – P.BE-CPX-CMAX-SYS-EN – en 2017-09b – English 29
Drive Compressed
air tubing
FittingValve
Type
Compressed
air tubing
DriveValve
Valve
Length [mm]Size
DGCI 40 100 … 300 VPWP-4-... QS-G1/8-8 QS-G1/4-8 PUN-8x1,25
360 … 750 VPWP-6-... QS-G1/4-8
850 … 2000 VPWP-8-... QS-G1/4-10 QS-G1/4-10 PUN-10x1,5
63 100 … 300 VPWP-6-... QS-G1/8-8 QS-G3/8-8 PUN-8x1,25
360 … 750 VPWP-8-... QS-G1/4-10 QS-G3/8-10 PUN-10x1,5
850 … 2000 VPWP-10-... QS-G3/8-12 QS-G3/8-12 PUN-12x2
DNC(I) 32 50 … 150 VPWP-4-... QS-G1/8-6 QS-G1/8-6 PUN-6x1
151 … 400 QS-G1/8-8 QS-G1/8-8 PUN-8x1,25
> 401 VPWP-6-...
40 50 … 250 VPWP-4-... QS-G1/8-8 QS-G1/4-8 PUN-8x1,25
> 251 VPWP-6-...
50 50 … 180 VPWP-4-... QS-G1/8-8 QS-G1/4-8 PUN-8x1,25
181 … 600 VPWP-6-...
> 601 VPWP-8-... QS-G1/4-10 QS-G1/4-10 PUN-10x1,5
63 50 … 100 VPWP-4-... QS-G1/8-8 QS-G3/8-8 PUN-8x1,25
101 … 350 VPWP-6-... QS-G3/8-10 PUN-10x1,5
> 351 VPWP-8-... QS-G1/4-10
DSMI 25 – (270°) VPWP-4-... QS-G1/8-6 QSM-M5-6 PUN-6x1
40 – (270°) QS-G1/8-8 QS-G1/8-8 PUN-8x1,25
63 – (270°) QS-G1/4-8
Tab. 3.6 Drive/valve combinations
