6.5.2 Information on the CMAX (menu [Module Data] )
The module data of the CMAX are displayed in the menu [Modul data].
System Overview _
CPX terminal
0: ... Module ...
1: ... Module ...
2: CMAX-C1-1 1 Serð
3: ... Module ...
_____________________________________________________
Diag ßà OK
2:CMAX-C1-1 _
Monitoring/forcing (M)
Diagnostics (D)
Parameters (P)
Module data (MD)
_____________________________________________________
Back OK
2:CMAX-C1-1 :MD _
1 Servopneumatic axis
Type code: 176
Revision: 2
Serial No: 0x83000024
_____________________________________________________
Back
1
2
1 Menu [Module data] 2 Information
Fig. 6.4 Displaying information with the CPX-MMI
Module data Description
Type code Module code (CPX-specific, for the CMAX: 176)
Revision Firmware design (e.g. 2 for version 2.00)
Serial No Serial number of the CMAX
