3. Diagnosis
3−12
Festo P.BE−CPX−FB13−EN en 0811c
In order to commission your system, it may be useful in some
cases to switch off the device−related diagnosis. If your
controller does not start, try with
the setting Device−related
diagnosis inactive" on the 8−element DIL switch (see section
1.2.2).
3.5.2 Overview of the diagnostic bytes
In the following the diagnostic bytes are represented in four
tables.
Standard diagnostic information
Byte Contents Explanation
1 Station status 1 see Tab.3/11
2 Station status 2 see Tab.3/12
3 Station status 3 see Tab.3/13
4 Diag.Master_add Master address: The address of the master that
parameterised the CPX terminal is entered in this byte
5 Ident_number high byte Manufacturer identifier high byte (05
h
)
6 Ident_number low byte Manufacturer identifier low byte (9E
h
)
Tab.3/7:Diagnostic bytes 1Ū6: Standard diagnostic information
