B.1.2 Send parameterisation data
Set_Prm The parameterisation data are sent to the CPX terminal by
the DP master via the function Set_Prm.
Octet 1: Station status
Bit Meaning Explanation
0  Reserved
1 
2 
3 WD_On Response monitoring of the CPX terminal on/off:
0 = Off
1 =On
4 Freeze_Req 0 = FREEZE mode not requested by the master
1 = FREEZE mode set by the master
5 Sync_Req 0 = SYNC mode not requested by the master
1 = SYNC mode set by the master
6 Unlock_Req Bit 7 Bit 6 Explanation
7 Lock_Req
0 0 min T
SDR
+ slave parameters may be overwritten
0 1 CPX terminal released for other masters
1 0 CPX terminal blocked for other masters
1 1 CPX terminal released for other masters
Tab.B/1: Octet 1: Station status
