2. Commissioning
2−55
Festo P.BE−CPX−FB13−EN en 0811c
2.3 Checklist for commissioning the CPX terminal with FB13
Recommendation:
If the safety concept of your machine/system permits,
commission the CPX terminal with all operating voltages
but without compressed air. You can then test the CPX
terminal without triggering undesired reactions.
Caution
The CPX terminal with field bus node for PROFIBUS−DP
also starts with incomplete configuration.
· Check the configuration and address assignment of the
I/Os on the CPX terminal. In order to do this, you can, if
necessary, force the I/Os (see CPX system manual
P.BE−CPX−SYS−...).
· An incomplete configuration will be displayed with the
diagnostics LED of the controller and in the online
diagnostics of your configuration software.
· Please observe the general commissioning instructions in
the CPX system manual.
· Make sure that the desired parameterisation of the CPX
terminal in the initialization phase or after field bus inter
ruptions is carried out by the module. This is to ensure
that if the CPX terminal is replaced, the new terminal will
also be operated with the desired parameter settings.
· Use spot checks if necessary to check the parameterisa
tion, e.g. with the configuration program or with the
handheld.
· Check the DIL switch settings and the field bus
configuration before using and replacing CPX terminals.
Please also observe the switching−on instructions in the
manual for your controller.
