A.1 Technical specifications of field bus node CPX−FB13
General information
General technical specifications see CPX system manual P.BE−CPX−SYS−...
Protection class as per EN 60529, CPX−FB13 fitted
completely, plug connector plugged in or fitted
with protective cap
IP65 / IP67
Protection against electric shock
(protection against direct and indirect contact
as per IEC/DIN EN 60204−1)
by means of a PELV circuit
(Protected Extra−Low Voltage)
Module code (CPX−specific) Remote I/O: 202
Remote controller: 153
Module identifier (in the handheld unit) Remote I/O:
FB13−RIO PROFIBUS remote I/O
Remote controller:
FB13−RC PROFIBUS bus node
Voltage supply
Operating voltage/load voltage see CPX system manual P.BE−CPX−SYS−...
Current consumption of field bus node CPX−FB13
from operating voltage supply for electronics/
sensors (V
EL/SEN
)
max. 200 mA (only CPX−FB13)
Electrical isolation bus interface opto−decoupled
Field bus
PROFIBUS chip SPC 3 with DPV1
Version RS485, floating
Type of transmission serial asynchronous, half duplex
Protocol PROFIBUS DP
Transmission speed 9.6 Ū 12000kBaud, automatic baud rate recognition
Cable type depends on the cable length and on the set field bus baud rate:
see the manual for your controller
