Festo CPX-FB13 - Parameterisation with the Handheld

2. Commissioning
2−51
Festo P.BE−CPX−FB13−EN en 0811c
Note
Module parameters can refer to:
 properties of the complete module
 properties of an individual channel of a module.
2.2.3 Parameterisation with the handheld
The handheld provides menu−guided access to the
parameterisation of the CPX terminal without configuration
software.
If the handheld has write access to the parameters, you can
no longer parameterise via the bus:
 System parameters
 Module parameters
Diagnostic memory parameters can still be parameterised via
the bus.
The value Use CPX system settings" with the system
para
meters for Fail Safe or Force Mode (see Fig.2/19) means:
The value of these parameters will not be modified when the
field bus system is switched on. Values already set with the
handheld or via DPV1 are retained.
Information about operating the handheld can be found in the
manual for the handheld P.BE−CPX−MMI−1−...
