2.2 Parameterisation
You can set the reaction of the CPX terminal individually by
parameterisation. A distinction is made between the following
parameterisations:
 System parameterisation, e.g.: switching off fault
messages, etc.
 Parameterisation of the diagnostics memory
 Module parameterisation (module and channel−specific),
e.g.: monitoring, settings in the event of faults, settings
for the debounce times of the inputs.
A
detailed description of the individual parameters as well as
basic information about application can be found in the CPX
system manual (P.BE−CPX−SYS−...).
Parameter lists for CPX I/O modules and CPX pneumatic in
terfaces can be found in the manual for the CPX I/O modules
(P.BE−CPX−EA−...).
2.2.1 Parameterisation when switching on
1
Master loads
parameter set
into the node
2 Node distributes
parameter set to
the modules
PLC/IPC
PROFIBUS−DP
Master
1
2
Fig.2/17: Sequence of the start parameterisation
