Festo CPX-FB13 - Configuration with a Siemens Master

2. Commissioning
2−22
Festo P.BE−CPX−FB13−EN en 0811c
2.1.4 Configuration with a Siemens master
The following sections describe the basic configuration steps
with the Siemens STEP7 configuration and programming
software.
Other controller systems may require other settings or a
different procedure. Information on operation with general
DPmasters can be found in appendix B.1.
The configuration examples shown in this chapter are based
on the use of a Siemens
SPS SIMATIC S7−300 and the
Siemens STEP7 Version 5.3 configuration and programming
software. Operation of the STEP7 software is assumed to be
known in the following.
Note
Various configuration programs are available for use in
conjunction with a Siemens master. Obser ve the
corresponding procedure for your configuration program.
Caution
Danger of malfunctions, damage or injuries to people
A valve terminal with defective configuration will also be
put into operation. However, only the modules which have
been correctly configured for type and position will be
activated.
Before commissioning, ensure that the connected
elements (e.g. actuators) do not perform any undesired or
uncontrollable
movements.
If necessary, disconnect the load power supply and
compressed air supply.
See also section 2.3, checklist for commissioning
