B. General DP master
B−6
Festo P.BE−CPX−FB13−EN en 0811c
Further octets
Octet Description Explanation
2 and 3 WD_Fact_1
WD_Fact_2
Range 1 Ū 255:
The response monitoring time of the CPX terminal is
transmitted with these two octets:
TWD [s] = 10 ms x WD_Fact_1 x WD_Fact_2
4 Minimum Station Delay
Responder (min T
SDR
)
The minimum time the CPX terminal must wait, before
the reply telegram may be sent to the DPmaster.
5 and 6 Ident_number Transmits the Ident. number (= 059E
h
) of the CPX
terminal; parametrizing telegrams to the CPX terminal
are only accepted if the transmitted and the programmed
Ident. numbers are the same.
7 Group_Ident Not supported by the CPX terminal
8 Ū 198 User_Prm_Data Information on the slave−specific parameters can be
found in section 2.2 and the CPX system manual
P.BE−CPX−SYS−... as well as in the manual for the
I/Omodules P.B E−CPX−EA−...
Tab.B/2: Octets 2 Ū 198
