3. Diagnosis
3−14
Festo P.BE−CPX−FB13−EN en 0811c
Channel−related diagnosis (variable length)
Byte Contents Explanation
30 Channel−related diagnostic module x byte 1 Contains module number
31 Channel−related diagnostic module x byte 2 Channel number and input/output
32 Channel−related diagnostic module x byte 3 Fault type and channel type
33 Channel−related diagnostic module x byte 1 Contains module number
34 Channel−related diagnostic module x byte 2 Channel number and input/output
35 Channel−related diagnostic module x byte 3 Fault type and channel type
... ... ...
60 Channel−related diagnostic module x byte 1 Contains module number
61 Channel−related diagnostic module x byte 2 Channel number and input/output
62 Channel−related diagnostic module x byte 3 Fault type and channel type
x, y, z: See explanation in the following text.
Tab.3/10:Diagnostic bytes 30 Ū 62: Channel−related diagnosis (details in section 3.5.5)
The following applies to entries in the diagnostic bytes
30Ū62 (channel−
related diagnosis):
Entries must be in ascending order by module number
without gaps: The entries must always be in the same
sequence as the module n
umbers, irrespective of the time
sequence of the diagnostic messages (if necessary, the
entries with large module numbers will be shifted).
In the case of module−oriented and ch
annel−oriented
faults on a module, only the module−oriented diagnostic
message will be entered.
If there are several channel−oriented faults on a mod
ule,
only the diagnostic message of the channel with the
lowest channel number will be entered.
A maximum of 11 diagnostic messages can be processed.
