A. Technical appendix
A−6
Festo P.BE−CPX−FB13−EN en 0811c
Analogue input and output modules Maximum number
in a CPX terminal
Start
parameters
per module
Ţ Rev. 15 ţ Rev. 20
Analogue 2−input module:
CPX−2AE−U−I
9 9 17
Analogue 4−input module:
CPX−4AE−I
6 8 27
Analogue 4−input module (temp. module for RTD sensors):
CPX−4AE−T
8 9 20
Analogue 4−input module (temp. module for TC sensors):
CPX−4AE−TC
8 9 19
Analogue 2−output module:
CPX−2AA−U−I
7 9 21
Tab.A/3: Number of start parameters, part 2: Analogue input and output modules
Technology modules
Maximum number
in a CPX terminal
Start
parameters
per module
Ţ Rev. 15 ţ Rev. 20
Soft stop end−position controller
CMPX without fail−safe
8 9 19
Soft stop end−position controller
CMPX with fail−safe
6 8 27
Multi−axis interface
CPX−CMXX
9 9 0
CPX−CP interface
CPX−CP−4−FB
see Tab.A/5
Tab.A/4: Number of start parameters, part 3: Technology modules
