A. Technical appendix
A−8
Festo P.BE−CPX−FB13−EN en 0811c
Pneumatics Maximum number
in a CPX terminal
Start
parameters
per module
Ţ Rev. 15 ţ Rev. 20
Pneumatic interface for VTSA or VTSA−F pneumatic
(ISO, type 44/45):
1)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
1 Ū 32 valve coils
1
1
1
1
1
1
1
1
6
9
12
15
Pneumatic interface for Midi/Maxi valves (type 03):
1)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
1 Ū 32 valve coils (26 can be used)
1
1
1
1
1
1
1
1
5
7
9
10
Pneumatic interface for CPA valves (type 12):
1)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils (22 can be used)
1
1
1
1
1
1
6
9
12
MPA1 pneumatic module
VMPA1−FB−EM...−8
2)
8 8 5
MPA1 pneumatic module with diagnostic function D2:
VMPA1−FB−EM...−D2−8
2)
8 8 7
MPA2 pneumatic module
VMPA2−FB−EM...−4
2)
9 9 4
MPA2 pneumatic module with diagnostic function D2:
VMPA2−FB−EM...−D2−4
2)
9 9 6
MPAP pressure sensor module
VMPA−FB−PS−...
4 9 12
VPPM proportional pressure−regulating valve (type 32)
VPPM−6TA−L−1−F...
9 9 18
1)
Setting with DIL switch in the pneumatic interface
2)
Type of MPA electronic module used
Tab.A/6: Number of start parameters, part 5: Pneumatics
