B. General DP master
B−13
Festo P.BE−CPX−FB13−EN en 0811c
Output data (Outp_Data) Input data (Inp_Data)
Octet 15: O−data byte_14
(CP interface continued, output module on
string 4)
Bit 0: Output (y+13).0
...
Bit 7: Output (y+13).7
Octet 16: O−data byte_15
(CP interface continued, assigned but
unused)
Bit 0: Output (y+14).0
...
Bit 7: Output (y+14).7
...
Octet 18 O−data byte_17
(8DI/8DO module, mod. no. 4, 8DX)
Bit 0: Output z.0
...
Bit 7: Output z.
7
Octet 19: O−data byte_18
(MPA1 pneumatic module, mod. no. 5,
8DO)
Bit 0: Output s.0
...
Bit 7: Output s.7
Octet 20: O−data byte_19
(MPA1 pneumatic module, mod. no. 6,
8DO)
Bit 0: Output t.0
...
Bit 7: Output t.7
Octet 6: I−data byte_5
(CP interface continued, assigned but
unused)
Bit 0: Input (v+3).0
...
Bit 7: Input (v+3).7
Octet 7: I−data byte_6
(8DI/8DO module, mod. no. 4, 8DX)
Bit 0: Input w.0
...
Bit 7: Input w.7
x, y, z, ... = address offset
Tab.B/7: Cyclic data exchange for example terminal 3  part 2
