2. Commissioning
2−5
Festo P.BE−CPX−FB13−EN en 0811c
Electric modules
Configuration in the
Remote I/O operating
mode
In the Remote I/O operating mode, the identifiers of the field
bus node (including diagnosis mode), the CPX modules and,
if present, the pneumatics are configured (see the following
tables and sections 2.1.4 or B.1):
Enter the identifiers corresponding to the physical sequence
of the modules from left
to right in your configuration pro
gram.
Electric modules
Module
identifier
1)
Identifier
Siemens/EN 50170
Assigned address
space
Description Inputs Outputs
Field bus node CPX−FB13
In Remote I/O operating mode:
without diagnostics access
FB13−RIO... 0/00
h
Field bus node CPX−FB13
In Remote I/O operating mode:
with status bits [Status]
FB13−RIO... 64 / 40
h
, 00
h
2 byte/
8 I
Field bus node CPX−FB13
In Remote I/O operating mode:
with I/O diagnostic interface
[System Table Interface, STI]
FB13−RIO... 192 / C0
h
, 81
h
, 81
h
2 byte/
16 I
2 byte/
16 O
1)
Module identifier in the handheld unit or in the hardware configuration of the programming software
Tab.2/1: Module over view and address assignment part 1: field bus nodes and
diagnosis mode
