2. Commissioning
2−10
Festo P.BE−CPX−FB13−EN en 0811c
Additional information on the pneumatics can be found in the
corresponding Pneumatics descriptions (see document over
view Descriptions of the CPX terminal" in the CPX manual
P.BE−CPX−SYS−...).
The manuals for the pneumatic valve cluster (Midi/Maxi, CPA,
MPA and VTSA/VTSA−F or ISO) contain the address assign
ment within the pneumatic modules.
For further information on
MPA pneumatic modules and the
pneumatic interfaces: see manual for the CPX I/O modules
(P.BE−CPX−EA−...).
CPX pneumatic interfaces
for MPA and MPApneuma
tics modules
Module
identifier
1)
Identifier
Siemens/EN 50170
Assigned address
space
ticsmodules
Inputs Outputs
Pneumatic interface for MPA or
MPA−F valves (type 32/33):
VMPA−FB−EPL−...
   
MPA1 pneumatic module
without separate circuits:
VMPA1−FB−EMS−8 
2)
MPA1S 8DO / 20
h
 1 byte/8 O
MPA1 pneumatic module
withseparate circuits:
VMPA1−FB−EMG−8
2)
MPA1G 8DO / 20
h
 1 byte/8 O
MPA2 pneumatic module
without separate circuits:
MPA2S 8DO / 20
h
 1 byte/8 O
without separate circuits:
VMPA2−FB−EMS−4 
2)
0/00
h
 4 bit O
3)
MPA2 pneumatic module
with separate circuits:
MPA2G 8DO / 20
h
 1 byte/8 O
withseparate circuits:
VMPA2−FB−EMG−4 
2)
0/00
h
 4 bit O
3)
1)
Module identifier in the handheld unit or in the hardware configuration of the programming software
2)
Type of MPA electronic module used
3)
Identifiers can be grouped together
Tab.2/6: Identifiers and address assignment part 1: MPA pneumatics
