2. Commissioning
2−12
Festo P.BE−CPX−FB13−EN en 0811c
CPX pneumatic interfaces
for VTSA (ISO), Midi/Maxi,
CPA
Module
identifier
1)
Identifier
Siemens/EN 50170
Assigned address
space
CPA
Inputs Outputs
Pneumatic interface for VTSA
or VTSA−F pneumatic
(ISO, type 44/45):
2)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
1 Ū 32 valve coils
ISO PlugIn or
type44 or
type45
3)
8DO / 20
h
16DO / 21
h
24DO / 22
h
32DO / 23
h
 1 byte/8 O
2 bytes/16 O
3 bytes/24 O
4 bytes/32 O
Pneumatic interface for
Midi/Maxi valves (type 03): 
2)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
1 Ū 32 valve coils
(26 can be used)
TYP3
8DO / 20
h
16DO / 21
h
24DO / 22
h
32DO / 23
h
 1 byte/8 O
2 bytes/16 O
3 bytes/24 O
4 bytes/32 O
Pneumatic interface for CPA valves
(typ e 12):
2)
1 Ū 8 valve coils
1 Ū 16 valve coils
1 Ū 24 valve coils
(22 can be used)
CPA10/14
8DO / 20
h
16DO / 21
h
24DO / 22
h
 1 byte/8 O
2 bytes/16 O
3 bytes/24 O
1)
Module identifier in the handheld unit or in the hardware configuration of the programming software
2)
Setting with DIL switch in the pneumatic interface
3)
Display text (module identifier) dependent on the version of the handheld unit
Tab.2/8: Identifiers and address assignment of the pneumatic interface par t 3:
MPA pressure sensor and
VPPM/MPA
Module
identifier
Identifier
Siemens/EN 50170
Assigned address
space
Inputs Outputs
MPAP pressure sensor module
VMPA−FB−PS−...
MPA−P 1AI / 50
h
1 word/
16 I

VPPM proportional pressure−
regulating valve (type 32)
VPPM−6TA−...
VPPM 112 / 70
h
1 word/
16 I
1 word/
16 O
Tab.2/9: Identifiers and address assignment of the pneumatics part 4
