2. Commissioning
2−29
Festo P.BE−CPX−FB13−EN en 0811c
Configuration with STEP 7
Assign the configuration table with the modules of your
CPXsystem (see Fig.2/8):
1. Click on the icon of the valve terminal to be configured in
the HW Config 1. The configuration table will be
displayed under the rack 2.
2. In the hardware
catalogue, open the module
Festo CPX terminal" (folder in the English version:
PROFIBUS−DP > Additional Field Devices > Valves >...") 3.
3. Pull the first (left−hand) module of your CPX terminal onto
line 0 in the configuration table. Repeat this step with
further modules of your CPX terminal. Drag each next
module onto
the next free line in the configuration table.
Assign the starting address in the window Properties 
DPslave"4.
Note
Drag the modules into the configuration table according
to the physical sequence (from left to right) of your CPX
terminal.
Modifying the address 1. Double−click on the appropriate line in the configuration
table.
2. Modify the starting address of the inputs/outputs in the
Properties  DP slave" window.
Note
With S7−400 controllers, up to 4 bytes of addresses are
reser ved for each DP identifier, depending on the version
status.
