B. Supplementary component summary
B-6
Festo P .BE-MPA-EN en 1108e
3/2-way valves
82/84
12/14
35
4
10
14
2
1
(12)
Ident. c ode: H
Function:
– On control side 14, one monostable 3/2-way
v alve (normally closed)
– On c ontrol side 12, one monostable 3/2-way
v alve (normally open)
– Pneumatic spring return
12/14 82/84
15 3
2
4
1014
Ident. c ode: HS
Function:
– On control side 14, one monostable 3/2-way
v alve (normally closed)
– On c ontrol side 12, one monostable 3/2-way
v alve (normally open)
– Mechanical spring return
82/84
12/14
3
5
4
14
2
1
12
Ident. c ode: K
Function:
– Two monostable 3/2-way valves
– Normally closed
– Pneumatic spring return
5
1
82/84
12/14
14
3
2
12
4
Ident. c ode: KS
Function:
– Two monostable 3/2-way valves
– Normally closed
– Mechanical spring return
