Festo MPS - Mechanical Set Up

6. Commissioning
84
© Festo Didactic 655633
6.2.1 Assembling profile plate and control console
1
2 (4x)
4 (
4x)
3
5 (2x)
6
1 Profile plate
2 T-head nut M6 x-32 (4x)
3 Trolley
4 Socket head screw M6x10 (4x)
5 Screw 3.5x9 (2x)
6 Control console
6.2
Mechanical set up
