MS6-SV-...-E-10V24
Festo – MS6-SV-...-E-10V24 – 1310b English 67
13.3 Fault correction when error code appears:
– Check the compressed air supply
– Check the voltage supply
– Check the installation of the signal lines
– Place the device in operation ( chapter 7 “Commissioning”)
– If the error occurs again, contact Festo Service.
Malfunction/
error code
Possible cause Remedy
2 Bouncing on the enable signals • Make sure that only debounced
contacts are used ( e.g. for protective
guards or doors).
5 Voltage supply is insufficient • Ensure that the voltage supply is
sufficient.
Power unit is not correctly dimensioned;
voltage collapses
• Ensure that the power unit is
sufficiently large.
6 Pressure supply wa s interrupted • Re - establish compressed air supply
8 Enable signals outside the specifications • Comply with specification
( chapter 7)
Multi-pin plug socket NECA-… or cable is
defective
• Check multi-pin plug socket NECA-…
or cable and replace if defective
Additional er-
ror codes
PLC emits test pulses that are off-set to
theenablesignals
• Switch off test pulses
•UseMP5plug
Malfunction due to electrical or electro-
magnetic effects (EMC information not
complied with)
• Comply with max. length of the signal
lines
• Connect earthing correctly
• Observe min. wall distance
• Do not install a cable behind
theMS6-SV-E
Pressure p1
collapses
briefly at every
switching op-
eration
Pressure supply o f th e MS6 - SV-E has too
little cross section
• Tighten flow control screw
• Attach reservoir in front of p1 inlet
• Adapt compressed a ir supply,
e.g. increase cross section of the
supply line
Throttle is opened too wide
Tab. 7 Trouble-shooting
