MS6-SV-...-E-10V24
Festo – MS6-SV-...-E-10V24 – 1310b English 69
14.2 General data
Type MS6-SV-E
Pneumatic connection 1, 2 G½ (ISO 228)
Pneumatic port 3 G1 (ISO 228)
Type of mounting In-line installation
With accessories
Design Piston seat not free of overlap
Actuation type Electric
Pilot air supply Internal
Exhaust function Without flow control
Position sensing principle Solenoid pist on principle
Manual override None
Reset method Mechanical spring
Type of control Piloted
Valve function 3/2-way valve, monostable, closed
Pressure build-up function
Mounting position Any
Operating medium Compressed air in accordance with ISO 8573-1:2010
[7:4:4]
Note on operating medium Lubricated operation possible (in which case lubricated
operation will always be required)
Ambient temperature [°C] –10 … +50 (0 … +50 with pressure sensor)
Temperature of medium [°C] –10 … +50 (0 … +50 with pressure sensor)
Storage temperature [°C] –10 … +50 (0 … +50 with pressure se nsor)
Shock resistance Shock test with severity level 2 according to
F N 942017-5 and EN 60068-2-27
Vibration resistanc e Transport application test with severity level 2
according to FN 942017-4 and E N 60068-2-6
Operating pressure [bar] 3.5 … 10
Cvalue [l/(s bar)] 19.3
bvalue 0.21
Standard nominal flow rate
1 > 2
[l/min] 4300(ifp1=6bar,p2=5bar)
Standard nominal flow rate
2 > 3
[l/min] 9000(atp1=6bar)
Min. standard nominal flow rate
2 > 3 in the most critical error
case
[l/min] 6000(ifp1=6bar)
Residual pressure in norma l
operation
[bar] 0 (no residual pressure)
Max. residual pressure in event
of error (worst case)
[bar] 0.4 (if p1 = 10 bar and flow control valve is fully open)
