Function
Chann
el
adressed
target
Index Meaning Value
digit
25 1 0 … 255 ID of the hardware info
è
Tab. 63 Hardware information 1
2 0 … 255 ID of the software info
è
Tab. 64 Software information 1
3 0 … 255 ID of the licence info
è
Tab. 65 Licence information 1
11 0 … 255 ID of the pressure value
è
Tab. 66 Pressure values 1
12 0 … 255 ID of the temperature value
è
Tab. 67 Temperatures 1
13 0 … 255 ID of the booster stroke value
è
Tab. 68 Booster strokes 1
14 0 … 255 ID of the flow rate value at the valve
è
Tab. 69 Flow rates
at the valve
1
21 0 … 255 ID of the proximity signal value
è
Tab. 70 Proximity sig-
nals
1
22 0 … 255 ID of the position value
è
Tab. 71 Positions 1
23 0 … 255 ID of the flow rate value at the external sensor
è
Tab. 72
Flow rates at the external sensor
1
31 – 1 … 40 Number of the position in the diagnostic memory with
content to be read
1
253 Position position latest diagnostic message of type
"error"
1
254 Position earliest diagnostic message of the "error" type 1
255 Number of diagnostic messages in the diagnostic memory 1
Tab. 59: Meaning of the indices per addressed target and channel
"Value" section (value)
This section is used to transfer numerical values. The significance and function of the numerical values
are defined by the sections described above.
Structure of the input data (PDI)
In transfer mode, the purpose of the input data (PDI) is to confirm the transfer that has taken place
or to output the requested value. To do this, the information that was transferred via "valve mode",
"channel", "transfer control", "addressed target" and "index" to the output data is returned to the
corresponding positions in the input data.
The "valve state" section shows the information described in section (
è
3.5.2.2 Structure of the input
data (PDI)).
