FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
4.4.3
Route QoS
The
route QoS includes route QoS enabling and route QoS
configuration.
4.4.3.1
Route QOS Enable
Enable
/ disable the route QOS function.
1. Select Security in the navigation bar and select Route QOS→
QOS Enable in the left link bar to open the route QOS enabling
tab, as shown in Figure 4.29.
Figure
4.29 Route QoS Enabling
2
. Select to Enable or Disable the route QOS function as
required.
3. Click Apply to save and apply the configuration.
4.4.3.2 Route QOS Configuration
While
configuring the route QOS parameters, user can classify the
queues based on priority and process the messages with high
priority first when system congestion occurs.
1. Select Security in the navigation bar and select Route QOS→
QOS Config in the left link bar. Then click Add to open the
route QOS configuration tab, as shown in Figure 4.30.
104

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
