FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
T
able 4.20 Parameters for Port Forwarding (Continued)
Item Description
Description The port forwarding rule name.
Public Port
The range of ports for Extranet data packets. If only one
port exists, enter the same port number.
IP
The IP address of the LAN virtual server for port
forwarding.
Private Port
The range of the LAN port for port forwarding. If only one
port exists, enter the same port number.
Protocol
The protocol used for the port to forward data packets,
including ALL, TCP and UDP.
Enable Enables or disables the rule.
4.5.4
Port Triggering
Port
triggering means that when the corresponding port at the LAN
side sends messages, the ONU will automatically enable the
designated port at the WAN side and map the port to the
corresponding port on the host that sends the messages at the LAN
side. In this way, normal communication can be guaranteed.
1. Select Application in the navigation bar and select Port
Trigger in the left link bar. Click Add to open the port triggering
configuration tab, as shown in Figure 4.39.
114

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
