FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
T
able 4.23 Parameters for DMZ Configuration
Item Description
DMZ Enable
Enables or disables the DMZ function. The options include
Enable, Disable and Auto. If Enable is selected, the DMZ
host IP address should be set. If Auto is selected, the DMZ
host uses the first IP address allocated by DHCP.
DMZ Host IP The host IP address of the DMZ.
4.5.8
Network Diagnosis
The
ONU provides two network diagnosis tools.
u Ping test: Test whether the router is normally connected with the
target host or another device.
u Traceroute test: Check the routing condition from the router to
the target host.
1. Select Application in the navigation bar and select Diagnosis
in the left link bar to open the network diagnosis tab, as shown
in Figure 4.43.
Figure
4.43 Network Diagnosis
2
. Enter the destination IP address to be tested in the Destination
Address box, and click Ping or Traceroute to test. The test
result will be displayed in the lower text box.
119

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
