FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
4.2.2
WAN Side Status
Select State in
the navigation bar and select Wan State in the left
link bar to view the information such as the status, IP obtaining
mode, IP address and subnet mask of the WAN side. See Figure 4.3.
Figure
4.3 WAN Side Status
4.2.3
LAN Side Status
Check
the state information about the LAN interface and the DHCP
client end.
LAN Side Status
Select State in the navigation bar and select Lan State→Lan State
in the left link bar to view the information such as the IP address,
subnet mask, service type and status of the LAN side. See Figure
4.4.
68

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
