FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
T
able 4.8 Parameters for TR-069 Configuration (Continued)
Item Description
Connection
Request
Authentication
Enables or disables the user authentication when the ACS
sends the connection request to the ONU.
Connection
Request
Username
Authentication username of the ACS sending the
connection request to the ONU.
Connection
Request
Password
Authentication password of the ACS sending the
connection request to the ONU.
Inform Enable
Enables or disables periodic report of Inform messages,
used for regular communication between the ONU and the
ACS. After the Inform message is enabled, the ONU will
authenticate and connect with the ACS at the end of each
informing interval, reporting the Inform messages for
information exchange between them.
Inform Interval
After the Inform message is enabled, set the time interval
of sending Inform messages (unit: s).
Get RPC
Methods
Click this button and the current ONU and ACS will
discover the operation methods supported by each other.
4.3.6
Authentication Setting
Configure
the parameters relevant to the ONU authentication mode,
so that the ONU can pass the OLT authentication.
1. Select Network in the navigation bar and select OLT
Authentication in the left link bar to open the OLT
authentication configuration tab, as shown in Figure 4.18.
88

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
