FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
T
able 4.22 Parameters for NAT Configuration
Item Description
WAN
The corresponding WAN connection bound with the NAT
rule.
Description
NAT rule name.
Rule Type
Select the NAT conversion mode. It is advisable to select
One-to-One or Many-to-One.
Locate Start IP
The starting IP address of intranet.
Locate End IP
The ending IP address of intranet.
Public Start IP
The starting IP address of the public network.
Public End IP
The ending IP address of the public network.
4.5.6
UPNP
The
UPnP supports the plug and play function and the automatic
discovery function of multiple network devices. When UPnP is
enabled, the devices that supports UPnP can be added into the
network dynamically. In this way, an external computer can access
the resource on the internal computer when necessary. For example,
when some application software are running on the PC, the port
mapping table will be generated on the ONU automatically using the
UPnP protocol, so that the operation can be sped up.
1. Select Application in the navigation bar and select UPNP in
the left link bar to open the UPNP configuration tab, as shown in
Figure 4.41.
117

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
