FiberHome AN5506-04 Series User Manual

3
Product Overview
T
able 3.3 Description of Indicator LEDs on the AN5506-04-A (Continued)
Indicator
LED
Meaning
Color Status
Status Description
LOS
Optical
signal
status
indicator
LED
Red
Blinking
The device has not
received the optical signal.
OFF
The device has received
the optical signal.
LAN1 to
LAN4
Ethernet
interface
status
indicator
LED
Green
ON
The interface is connected
to the user terminal and no
data is transmitted.
Blinking
The interface is
transmitting / receiving
data.
OFF
The interface is not
connected to the user
terminal.
Power
Power
status
indicator
LED
Green
ON
The device is powered on.
OFF
The device is not powered
on.
3.2
Introduction to the AN5506-04-B
The
AN5506-04-B is an FTTH-type GPON ONU. It provides users
with communication and entertainment services in the form of data,
voice, video, and so on, to meet the integrated access demand of
families and small-scaled enterprises.
Appearance
The overall appearance of the AN5506-04-B is shown in Figure 3.3.
8

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
