FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
Figure
4.19 IPv6 Static Routing
2
. Configure the parameters relevant to static routing as required.
Table 4.10 describes the parameters.
3. Click Apply to save and apply the configuration.
T
able 4.10 Parameters for the IPv6 Static Routing
Item Description
DstPrefix
The destination IP address to be accessed by the host.
Nexthop The IP address of the next-hop gateway.
WAN
The WAN port passed by the static routing. Select the
available WAN port.
4.4
Security
The
following introduces how to configure the firewall, remote
control, route QOS, WPS, ACL configuration, DDOS and HTTPS in
Web GUI.
90

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
