FiberHome AN5506-04 Series User Manual

4
Web Configuration Guide
T
able 4.25 Parameters for the FTP Client End
Item Description
Type Select to upload or download.
Username The FTP server username.
Password
The FTP server password.
FTP Server IP The FTP Server IP address.
FTP Server Port
The FTP server port.
Remote File Name The name of file saved in the FTP server.
Disk NO.
The disk number of the USB port connected to
the ONU.
Local File Name
The name of file saved locally.
4.6.2.5
FTP Server
With
the FTP server function of the ONU enabled, users can access
the ONU resources via the FTP client end on the PC.
1. Select Management in the navigation bar. Select Device
Management→FTP Server from the left link bar to open the
FTP server configuration tab, as shown in Figure 4.50.
Figure
4.50 FTP Server
2
. Enable or disable the FTP server function according to the
requirement.Select Enable and then enter the Username and
Password for connection with the FTP server.
125

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
