4
Web Configuration Guide
Figure
4.52 NTP Time Calibration
2
. Configure relevant parameters relevant to the NTP time
calibration. Table 4.26 describes the parameters.
3. Click Check Time to save and apply the configuration.
T
able 4.26 Parameters for NTP Time Calibration
Item Description
Enable NTP Check
Time
Select whether to enable the NTP time calibration
function.
seconds
Sets the time interval for synchronization with the
time server.
First NTP Server Enter the IP address of the active NTP server.
Second NTP Server
Enter the IP address of the standby NTP server.
Time Zone
Select the time zone according to the location of
the device.
4.6.3
Log
The
Log files record key operations and behaviors on the ONU.
Users can view or download the information saved in log as needed.
1. Select Management in the navigation bar. Select Device
ManagementLog from the left link bar to open the log view
tab, as shown in Figure 4.53.
127
