FiberHome AN5506-04 Series User Manual

3
Product Overview
T
able 3.4 Technical Parameters of the AN5506-04-B (Continued)
Type
Item
Description
Supports global configuration of queue priority
and flexible mapping of 802.1p values in
packets.
Supports three queue scheduling modes (PQ,
WRR and PQ+WRR); supports configuring the
weight of the scheduled queue, so as to
guarantee the service quality of high-QoS
services such as voice and video in the multi-
service environment.
Network
side
interface
GPON
interface
Provides one GPON interface (SC/UPC or
SC/APC interface), supporting transmission
distance up to 20km and complying with the
ITU-T G.984 standard.
Supports Class B+, with receiving sensitivity
less than -29 dBm.
User side
interface
LAN interface
Provides four LAN interfaces (RJ-45
interfaces), supporting full-duplex or half-duplex
and 10/100/1000M auto negotiation. The
maximum transmission distance is 100m.
MAC address capacity: 1K
Phone
interface
Provides two phone interfaces (RJ-11
interfaces).
Table 3.5 Specifications of the AN5506-04-B
Type
Item
Description
Mechanical
parameters
Dimensions
32mm × 170mm × 130mm
(height x width x depth).
Wall mounting hole
distance
83mm
Weight About 256g
11

FiberHome AN5506-04 Series Specifications

General

Model	AN5506-04 Series
Category	Network Hardware
Type	GPON ONT
Power Supply	12V DC, 1A
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Ports	4 GE ports, 2 POTS ports
WLAN	802.11b/g/n
