FT-50 Fill Level Inspector Operation Guide
2-10 Industrial Dynamics Company, Ltd. Document 40272-0700
3.
Center a properly filled and capped production container in the
inspection tunnel so that it is directly under the missing cap sensor.
4.
Find your type of missing cap sensor in the table below and adjust the
upper jam nut to raise or lower the sensor to the proper height.
5.
When you achieve the proper height, tighten the lower jam nut to
secure the sensor positioning.
6.
If you closed the manual safety shutter, open it before resuming
operation. For more information see “The Safety Shutter” on
page 2-3.
Description (Cap Type) Maximum Height Above Cap
Nonferrous (Aluminum) 0.4 inch (10 mm)
Photo-Optic Sensor (All) 0.7 inch (18 mm)
Extended Range (Aluminum)
Extended Range (Steel)
0.5 inch (13 mm)
0.88 inch (22 mm)
Steel Cap Under Aluminum Foil 0.3 inch (8 mm)
Standard 0.25-0.38 inch (6-9 mm)
Bifurcated fiber-optic Sensor 0.7 inch (18 mm)
