FT-50 Fill Level Inspector Operation Guide
3-2 Industrial Dynamics Company, Ltd. Document 40272-0700
The Operator Control Panel
You can interact with the FT-50’s through the operator control panel. The
control panel contains eight keys and a two-line LCD (Liquid Crystal
Display) capable of displaying 24 characters per line.
A remote, hand-held control is also available. The remote control panel
detaches from the FT-50 thereby allowing easier access.
Figure 3-1.
The FT-50’s operator control panel.
?
6
INDUSTRIAL DYNAMICS
Torrance, California USA
4
3
5
1
2
