Filtec FT-50 - Aligning the High Cap Sensor

Chapter 2: Operating Your FT-50
Industrial Dynamics Company, Ltd. Document 40272-0700 2-11
Aligning the High Cap Sensor
Figure 2-5.
Aligning the high cap sensor
6
1
2
3
4
5
8
7
No. Description
1 Sensor Emitter
2 Height Adjustment Lock
3 Container Cap
4Sensor beam
5 Sensor Receiver
6 Container Travel
7 Distance between Container Cap and Sensor Beam
8 Secondary Sensor Height Adjustment
