FT-50 Fill Level Inspector Operation Guide
2-12 Industrial Dynamics Company, Ltd. Document 40272-0700
The high cap sensor is mounted on a u downstream offset bracket
attached to the centerline trigger bracket. Therefore before you align the
high cap sensor, be certain the centerline trigger bracket is aligned
properly. For more information see “Adjusting the Centerline Trigger
Bracket Height” on page 2-7.
1.
If your FT-50 is not equipped with an automatic safety shutter, you
must close the manual shutter before you proceed. For more infor-
mation see “The Safety Shutter” on page 2-3.
2.
Center a properly filled and sealed production container under the
downstream sensor mounting bracket.
3.
Loosen the downstream sensor mounting bracket adjustment knob
and adjust the sensor so that it is 1mm above the container cap.
Note
If you do not have enough adjustment range to position the sensor
correctly, reposition the sensor receiver and emitter in the bracket by
moving it up or down 1 or 2 hole positions to give you the range you
need.
4.
Tighten the adjustment knob to secure the positioning.
5.
If you closed the manual safety shutter, open it before resuming
operation. For more information see “The Safety Shutter” on
page 2-3.
