Filtec FT-50 - Aligning the Bulged Can Sensor

Chapter 2: Operating Your FT-50
Industrial Dynamics Company, Ltd. Document 40272-0700 2-19
Aligning the Bulged Can Sensor
Figure 2-9.
Aligning the bulged can sensor
6
1
2
3
4
5
8
7
No. Description
1 Sensor Emitter
2 Height Adjustment Lock
3 Container Lid
4Sensor Beam
5 Sensor Receiver
6 Container Travel
7 Distance between Container Lid and Sensor Beam
8 Secondary Sensor Height Adjustment
