FT-50 Fill Level Inspector Operation Guide
2-14 Industrial Dynamics Company, Ltd. Document 40272-0700
Caution
Do not use the smashed bottle function to detect the container base only.
If the container is smashed down to the base it cannot be rejected properly
and may damage the rejector.
3.
Loosen the upstream sensor mounting bracket adjustment knob and
adjust the sensor so that it contacts the bottle 1mm-2 mm below the
point where the container is smashed.
Note
If you do not have enough adjustment range to position the sensor
correctly, reposition the sensor receiver and emitter in the bracket by
moving it up or down enough hole positions to give you the range you
need.
4.
Tighten the adjustment knob to secure the positioning.
5.
If you closed the manual safety shutter, open it before resuming
operation. For more information see “The Safety Shutter” on
page 2-3.
