MS-9200UDLS/E/C Manual — P/N 52750:F 7/26/2010 117
Master Programming Level Programming
3.6.9 Option Modules
Options available for the MS-9200UDLS include ANN-BUS annunciators, legacy ACS BUS
annunciators, and the LCD-80F Terminal Mode annunciator, printer connection for acquiring
hardcopy printouts of panel data, and PC (Personal Computer) connection for uploading and
downloading panel data.
Pressing 3 while viewing Programming Screen #3 will display the following screen:
Note that PR4800 in the display indicates that a supervised printer, configured for 4800 baud, has
been previously programmed into the system.
Annunciators
Pressing 1 while viewing the Options Screen will cause the control panel to display the following
screens:
An LCD-80F Terminal Mode annunciator, ACS BUS annunciator, or ANN-BUS
annunciator/module can be installed in the MS-9200UDLS system. Refer to “Guidelines” on
page 22 for rules governing the use of various annunciator types. Do not use a mix of ACS
annunciators and ANN annunciators since they use different communication protocols. ACS or
ANN annunciators use the same TB9 terminal block connection. To install any of these devices,
press the number corresponding to the desired device shown in the Annunciator Screen.
Term Options
While viewing the Annunciators screen, each press of the 1 key for Term Enabled, will cause the
display to toggle between Term Enabled No and Term Enabled Yes.
Notes:
1. The LCD-80F is a Terminal Mode annunciator. To enable the MS-9200UDLS for -LCD-80F
operation, press 1 for Term Enabled Yes.
2. The Terminal Mode annunciator (LCD-80F) and the Printer/PC use the same TB8 terminal
block on the MS-9200UDLS main circuit board. Only one device can be connected at one
time, therefore, enabling an annunciator in the Term Option will disable any Printer/PC com-
munications.
PROGRAMMING
1=HISTORY
2=WALKTEST
3=OPTION MODULES
Programming Screen #3
OPTION MODULES
1=ANNUNCIATORS
2=ONBOARD DACT
3=PRINTER/PC PR4800
Options Screen
ANNUNCIATORS
1=TERM ENABLED NO
2=ACS OPTIONS
3=ANN-BUS OPTIONS
To Next Page
